SOMMER evo+ Garage Door Opener

$299.97
SOMMER  |  SKU: YS10256-00001

Direct drive technology with one moving part for maximum force and longevity
For use on standard lift or low headroom sectional doors, one-piece doors, up-and-over doors, canopy doors, roof pitch doors, and extreme breakaway high lift doors
Soft start and stop on a variable curve ramp
Dynamic force and speed settings automatically adjust over time for changing door and environmental conditions to optimize safety and operation
Active motor braking during travel helps minimize loss of control during door malfunction
Operator actively pushes in the closed direction during attempted break-in
Emergency release can be disengaged and re-engaged in any position
Built-in LED lighting at the motor carriage
Easily cut down rail and chain for tight spaces and/or use Connector Wire and GDO Connection Coupler to gain additional travel (see Header to Obstruction Chart)
Add Short, Medium, or Long Rail Extension for taller doors up to 24' (see Door Height by Rail Extension Chart)
Monitored safety edge and optical safety edge terminals on motor carriage to avoid coil cords or take up reels
Interlock capable for pass doors, mechanical locks, etc.
Pre-programmed 4-button Pearl transmitter in the box
Repeating and forwarding radio functions for maximum range
Use Pearl Vibe or Slider Vibe transmitters for live feedback from operator
Multiple functions available through radio commands: pulse operation, light function, partial opening, defined open, and defined close
Transmitter management on-site or remotely through Codemaster+
Accu internal battery back up or Accu 2.2 external battery back up provide power for standby operation during power outages
Compatible with SOMweb for remote access and monitoring by push notifications and/or with live in-app indoor or outdoor camera feed
Use Telecody Courier for parcel delivery to your garage with any delivery service--opening distance is adjustable by homeowner
Automatic closing in either semi-automatic or fully automatic modes (Buzzer required for activation)
Use Relay for switching external garage lighting up to 240V/5A
Maintenance-free for most environments
Motor carriage can be easily removed for service or repair without needing to disassemble rail
~100 settings adjustments, ~60 diagnostic features, and ~180 standard operating codes available through SOMlink service interface

  • 3-piece c-channel rail for doors up to 8' tall
  • One 4-button Pearl transmitter included
  • Wired safety sensors
  • Wired 3-button wall station

Evo+ Specifications

The SOMMER evo+ garage door opener features our most advanced garage door control unit with various optimised speed profiles and the option of precision setting of the operating forces. The garage door opener also learns continuously and automatically and adjusts the door operation accordingly.

A table comparing the facets of 1 products
Standard Door Height
Standard Door Height7' and 8' doors
Motor Power
Motor Power600 N up to 1100 N
Max Travel Speed
Max Travel SpeedFrom 9.4 down to 7.0 inch/second
Overall Length
Overall Length140"
Max Door Height w/ Extensions
Max Door Height w/ Extensions23'
Max Travel Speed
Max Travel Speed
-
Power Consumption (Standby)
Power Consumption (Standby)< 2 Watts
Number of Programmable Remote Buttons
Number of Programmable Remote Buttons40
Connection for Warning Light
Connection for Warning LightYes (DC 24V | 25W)
Radio Frequency
Radio Frequency922.5 MHz
Homelink Compatible
Homelink CompatibleYes
Shipping Dimensions
Shipping Dimensions44.5" x 7.5" x 5.0"
Connection for Safety Edge
Connection for Safety EdgeYes

How to Install the evo+

The all new SOMMER evo+ garage door opener is a class of its own.
